 2. A transmission line 500 kilometres long has a reactance of 200 ohms per phase and a line-to-neutral capacitance of 800 ohms per phase. Its equivalent circuit per phase can be approximated by the circuit shown on Fig. 4-7. If the line-to- line voltage at the sender end S is 330 kV, what is the line-to-line voltage at the receiver end R when the load is disconnected? 100 Ω 100 Ω 800 Ω Figure 4-7. Calculate the reactive power of the source in kvar. Is this power supplied or absorbed by the source? What is the full answer of this question ?

Show transcribed image text

Expert Answerinformation icon

  • Anonymous's Avatar
    Anonymous answered this
    41 answers

    Comment
